eCactus PowerPod Agave-SH Ultra 8kW Inverter & 20kWh Battery system
eCactus PowerPod Agave-SH Ultra 8kW Inverter & 20kWh Battery system
Regular price
$19,500.00 NZD
Regular price
Sale price
$19,500.00 NZD
Unit price
/
per
Please email us for trade pricing: sales@wholesale-solar.co.nz
Couldn't load pickup availability
Overview
eCactus PowerPod AGAVE-SH Ultra (8 kW + 20 kWh) is an all-in-one home energy storage system combining a high-efficiency single-phase inverter with stackable LiFePO4 battery modules. It’s ideal for residential solar + storage, backup power, and off-grid/edge-of-grid setups. Quiet operation and certified multi-layer protection make it installer-friendly and homeowner-safe.
Key Highlights
- All-in-One: Integrated inverter + batteries in one system (faster installs).
- Output: 8,000 W continuous (230 V single-phase).
- Storage: 4 × 4.99 kWh modules (≈ 20 kWh total). Scalable with parallel hub.
- UPS-grade backup: <10 ms switchover keeps loads running during outages.
- Fast charge/discharge: 50 A.
- Cold-climate option: add battery heaters for operation down to −20 °C.
- Safety: Four-layer protection incl. BMS, AFCI support, and UL9540A testing.
- Quiet: <25 dB—suitable for indoor utility cupboards/garages.
Technical Specifications (8 kW model)
| PV Input (DC) | Max PV power 16,000 W; Max voltage 600 V; MPPT range 50–560 V; Max current 64 A (4 × 16 A) |
|---|---|
| Battery | LiFePO4; 4.99 kWh per module; Max system ~19.9 kWh (4 modules); Voltage 80–500 V; 50 A charge/discharge |
| AC Output | Rated 8,000 W / 8,000 VA; 230 V; 26.1 A; 50/60 Hz |
| EPS/Backup | Rated 8,000 W; Surge 2× rated; Transfer time <10 ms |
| Efficiency | Max inverter efficiency 98%; PV→Battery 98.5% |
| Dimensions/Weight | Inverter: 600 × 750 × 380 mm (~27.4 kg); Battery: 600 × 570 × 380 mm (~57 kg/module) |
| Protection | DC isolation, surge protection, integrated BMS, AFCI support |
| Compliance | IEC/EN 62109, UN38.3, UL9540A, IEC 62619, CE, EMC, CAN/RESI, AS/NZS standards |
Applications
- Solar + Storage: store daytime PV for evening use and peak-shaving
- Backup Power: seamless UPS transition for critical household loads
- Off-Grid/Remote: scalable storage with optional cold-weather heaters
What’s Included
- PowerPod AGAVE-SH Ultra inverter module (8 kW)
- 4 × 4.99 kWh battery modules (≈ 20 kWh total). For >4 modules, use parallel hub.
- Integrated BMS
- Installation manual & safety documentation
Installer Notes (NZ/AU)
- Single-phase 230 V output—confirm load segmentation for essential vs general circuits.
- Observe clearances/anchoring due to stacked battery mass; follow manufacturer wall/floor mount guidance.
- Commission per manual including BMS setup, SOC calibration, and EPS test (<10 ms transfer).
- Verify compliance to applicable AS/NZS standards and local DNSP requirements.
